ZX-8 VERTICAL MULTI LINES FOUR SIDE SEAL POWDER / LIQUID PACKING MACHINE

ZX-8 VERTICAL MULTI LINES FOUR SIDE SEAL POWDER / LIQUID PACKING MACHINE

Model: ZX-8
Scope: packing liquid and sauce material such as hair shampoo,Body shampoo, cream, seasoning oil, jams, ketchup, sauce etc.
Technology parameters
MODEL NO. ZX-8
Power Supply single phase 220V/50Hz
Packing Material OPP/CPP、OPP/CE MST/PE、PET/PE
Packing Film Thickness 0.06-0.1mm
Packing Film Width Range 480-995mm
Single Line Pouch Size 60mm(W) 60-120mm(L)
Single Line Packing Speed 40bags/min
Total Power 13KW
Vertical Sealing Heaters Power 1.5kwX4/220V AC
Horizontal Sealing Heaters Power 1.5kwX2/220V AC
Working Air Pressure 0.8MPa
Air Consumption 0.8m /min
Gross Weight 450kg
Outside Dimensions 1885mm x 1600mm x 2200mm

Main performance and structural characteristics:
Vertical multi lines four side seal powder/liquid packing machine is a high-powered automatic packing machine. It includes all the actions like bag making, material sending, counting, filling, sealing, date printing and finished product outputting. This machine adopts high precision servo to control the film sending .It has PLC control system,advanced touch screen HIMI mode, PH sensor automatic tracking,digital temperature controller etc. It is the first choice for the company to enhance productivity
