Bubble Gum Production LineYour Location: Home > Candy Production > Bubble Gum Production Line > Bubble Gum Series
ZX-300II SPECIAL SHAPE CENTRE FILLED CREAM CANDY AND BUBBLE GUM PRODUCTION LINE

Scope:
This line is suitable for producing all kinds of shapes of cream candy, hard candy and bubble gum. It can produce many shapes of candy, such as hollow, sandwich and filling-with-pulp candy in the shapes of ball, strawberry, oval, column and so on.



Main performance and structural characteristics:
The whole set of line is composed by mixer, extruder, conveyer belt, special shape candy or bubble gum forming machine (six sets), coating pan (six sets).



Production line performance technical parameters
Production Capacity(kg/hour) 600~650
Diameter Of Granule Forming(mm) 10~25
Main Power(kw) 69
Working Voltage(v) 380
Outside Dimensions(mm) 15000×4000×1500
Gross Weight(kg) 8850



名称 NAME 功率
Main Power(kw)
外形尺寸
Outside Dimensions(mm)
整机重量
Gross Weight(kg)
搅拌机
Mixer
22 2600x1230x910 1500
挤出机(双色)
Extruder(Two color)
20 2500×1180×1550 2200
振动输送带
Vibrating & Conveyer Belt
3 12000×750×1200 650
异形糖成形机
Special Shape Forming Machine
2.2×(6台) 1500×900×1200×(6台) 400×(6台)
糖衣机
Coating Pan
3.55×(6台) 1380×1720×1000×(6台) 350×(6台)
夹心泵
Sandwich Pump
4.5 1600×500×1050 300
泡泡糖胶基烤箱
Bubble Gum Base Oven
12 2400×720×1600 750
